Single Core & Multi Core Cables Wires Manufacturers in Delhi

Single & Multi Core Cables Wires Manufacturers — Hyphen Cables

Hyphen Cables is a trusted single core and multi core cables wires manufacturer in Delhi, India, serving EPC contractors, OEMs, utilities, real estate projects, and retail channels. We engineer safe, durable, and energy-efficient cabling solutions across PVC, FR, FRLS, LSZH and XLPE constructions, tailored for Indian conditions and global

Why Choose Hyphen Cables?

Application-centric designs: Optimized for power, control, instrumentation, telecom, and solar BOS.
Stringent quality: 100% conductor resistance & high-voltage testing, online spark testing, and ageing studies.
Reliable materials: Electrolytic annealed copper (99.97% purity), premium PVC/XLPE compounds, UV & moisture protection.
Compliance-ready: IS 694/IS 7098, IEC/BS references, RoHS, FR/FRLS/LSZH options, CPR-style parameters on request.
Custom manufacturing: Core count, stranding class, colour codes, print legends, and drum lengths per spec.

Product Range — Single & Multi Core Cables/Wires

Single Core Cables/Wires

House Wires: 0.5–6.0 sq.mm, PVC FR/FRLS/LSZH, 1100 V grade, vibrant colour coding for circuits.
Flexible Industrial Leads: 0.5–50 sq.mm, Class 5/6 stranding for high flexibility and easy routing.
Battery & Welding Cables: High current, abrasion resistant sheath, temperature stable.
Earthing/GI/Cu Conductors: Green/Yellow-Green identification, low resistance paths.

Multi Core Cables

2–61 Core Control Cables: Number-coded/colour-coded, overall/individual screens available.
Instrumentation Cables: Twisted pairs/triads, AL-Mylar shields, drain wire, low noise.
Power & Armoured Cables: 1.1 kV grade, XLPE insulation, steel strip/wire armouring.
Data/Signal & Composite: Hybrid builds combining power + signal for compact harnesses.

Typical Specifications

Parameter	Single Core	Multi Core
Conductor	Annealed bare/tinned copper, Class 1/2 (solid/stranded) or Class 5 flexible	Annealed bare/tinned copper, Class 2/5, paired/twisted as required
Insulation	PVC FR/FRLS/LSZH or XLPE	PVC/XLPE with options for PE/LSZH; coded or numbered cores
Shielding	Optional AL-Mylar + tinned copper drain	Overall or individual pair shields; braided/taped options
Sheath	PVC/LSZH/HR-PVC; UV resistant on request	PVC/LSZH/PE; armoured (SWA/STA) variants available
Voltage Grade	300/500 V, 450/750 V, 1.1 kV	300/500 V, 450/750 V, 1.1 kV
Standards	IS 694, IEC 60227/60228	IS 694 / IS 7098 (as applicable), IEC 60228, IEC 60502
Temperature Range	-15°C to +70°C (PVC), up to +90°C (XLPE)	-15°C to +70°C (PVC), up to +90°C (XLPE)
Flame Performance	FR/FRLS/LSZH to relevant IEC/IS flame tests	FR/FRLS/LSZH, low smoke & low toxicity options
Packaging	90 m coils, 100 m/180 m/200 m, or custom drums	500 m–1000 m wooden drums or as specified

Values above are indicative. Hyphen Cables builds to project-specific datasheets and tender requirements.

Manufacturing & Quality Assurance

Conductor drawing & stranding: Tight DC resistance and circularity for lower losses.

Compounding & extrusion: In-house PVC/XLPE with controlled gel content and insulation eccentricity.

Online spark & HV tests: Detects pin-holes and insulation defects instantly.

Laboratory checks: Tensile/elongation, ageing, heat shock, insulation resistance, sheath integrity.

Traceability: Batch coding and print legends for lifecycle accountability.

Applications

Internal building wiring, lighting, and power distribution

Control panels, machine wiring, conveyors, and automation lines

UPS, DG sets, battery banks, EV charging auxiliaries

Process instrumentation, PLC/DCS, low-noise signal runs

Solar plants (string/DC wiring, monitoring, BOS)

Underground/armoured runs for harsh environments

Customization Capabilities

Core count (2–61), cross-sections (0.5–400 sq.mm)

Class 2/5/6 stranding, tinned or bare copper

Shielding (foil/braid), armour (SWA/STA), drain wires

Colour coding, numbering, pair/triad configurations

Sheath compounds: UV/ozone/chemical resistant

Print legend, meter marking, and bespoke drum lengths
